Aircraft brake pad riveting machine,CNC riveting machine
Aircraft brake pad riveting machine,CNC riveting machine
JM12QA(Aircraft brake pad riveting machine) Characteristics:
Mechanical turnover,easy assembly rivet
Dividing device,automatic alignment and lock
5.6 Inches color LCD touch screen
Riveting height can be controlled
Riveting pressure and speed stepless adjustable
Riveting surface smooth & beautiful
Applicable for all kinds of specifications and single side or double side brake pad‘s process JM12Q-A aircraft brake pad riveting machine is special designed for China Southern Airline Service Department developed special purpose riveting machine for process aircraft brake pad, this machine can process various specifications and types of aircraft brake pad such as Boeing aircraft, McDonnell aircraft, and airbus etc.
Specification:
Max.pressure 20Kn
Stroke 30mm
Max.processing ablity Ф12mm
Available working space 145mm
Throat depth 160mm
Riveting tool length 50mm
Eccentric angle 4°
Rotation rate 960rpm
Power 0.75Kw
Physical size 820mmx850mmx1450mm
net weight 320Kg
