Double Coloumn Radial Drilling Machines Wholesaler Manufacturer Exporters Suppliers Punjab India

Double Coloumn Radial Drilling Machines

Technical Features

Specifications	RP-32	RP-40	RP-50
Drilling Capacity in Mild Steel	32 mm	40 mm	50 mm
Maximum Drilling Radius	750 mm	1050 mm	1300 mm
Max. Distance between Spindle and Base	825 mm	1000 mm	1250 mm
Spindle Travel	175 mm	180 mm	250 mm
No. of Spindle Speeds	6	6	12
Range of Spindle Speeds RPM	90-900	90-900	45-1000
No. of Spindle Feeds	3	3	6
Range of Spindle Feeds mm/ rev.	0.1-0.4	0.1-0.4	0.12-1.25
Main Drive Motor	2 HP	3 H.P	5 H.P
Elevating Motor	1 H.P	2 H.P	3 H.P
