I. Mx6q Mother Board Cortex-A9 1GHz Linux & Android

I.MX6Q Mother Board Cortex-A9 1GHz Linux & Android CPU NXP Cortex-A9 i.MX6Q, main frequency 1GHz RAM 1GB DDR3 eMMC 8GB eMMC PMIC MMPF0100F0ZES chip GPU VivanteGC355, VivanteGC320 Core Board connection way Array board 4G Quectel EC20, CNC WiFi & Bluetooth RL-UM02WBS-8723VAU GPS LW1613 Camera OV3640, 3million pix Ethernet 1*Gigabit Ethernet, RJ45 AUDIO 1*I2S I2C 2 SPI 1*SPI CAN 1*CAN bus interface RS485 1*RS485 SD/MMC/SDIO 2(1 with SD/MMC) USB HOST 2*USB HOST interface, support USB 2.0 UART 4*UART HDMI 1*HDMI LCD Support 10.1 inch LVDS(1280*800)HD display and 7 inch RGB display PWM 1,for debugging backlight VGA 1*VGA SATA 1*SATA RTC Real-time clock Button 5 CES-i.MX6Q Development Platform Software Parameter Operating system Linux 3.0.35 System boot program U-boot2008.09 Cross compile tool arm-fsl-linux-gnueabi-gcc-4.6.2, i.MX6 special ARMv7, support Hard-float operation System file format EXT4/NFS/FAT32 4G drive Support web browsing, sending and receiving text messages, to provide the sourcecode WIFI & BT drive Support 802.11b/g/n, provide the source code GPS drive Support SIF III global location, provide the source code Camera drive Support OV3640, provide the source code Ethernet drive support Gigabit Ethernet, provide the source code VGA drive HD display, provide the source code SATA drive support SATA, provide the source code AUDIO drive WM8962 mother, using I2S communication, provide the source code UART drive Support 4* serial communication, provide the source code LCD drive Support 10.1 inch LVDS(1280*800)HD display and 7inch RGB display, provide the source code TOUCH drive GT92X, support single point capacitive touch, provide the source code SD/MMC drive Support high speed of MMC and SDIO, provide the source code USB OTG drive HOST/Device drive, Device supports ADB, provide the source program USB HOST drive HOST,support mouse,keyboard,U disk and Bluetooth and other USB devices, provide the source code eMMC drive Support 8G, provide the source code
