MOTORIZED GYROSCOPE TOM 107
MOTORIZED GYROSCOPE TOM 107
The gyroscopic couple can be determined EXPERIMENTS:- Experimental justification of the equation T = l w. wp for calculating the gyroscopic couple by observation and measurement of results for independent vibrations in applied couple T and precession wp. To study the gyroscopic effect of a rotating disc. Observation of gyroscopic effect of rotating disc. UTILITIES: - Electric supply: 230 V AC, Single Phase. Bench area : 1m x 1m Tachometer to find out RPM of disc. TECHNICAL SPECIFICATION: - Disc : Material Stainless Steel Dia : 300 x 12 mm thick precisely balanced which can be rotated in 3 mutually perpendicular axis Electrical Motor : Variable speed of standard make. Supplied with Speed Control Unit. Weight : 2 Kgs, 1 Kg, ½ Kg. Stop Watch : Electronic Accurately marked scale & pointer to measure precession rate The whole Set-up is well designed and arranged in a good quality painted Structure
Send Enquiry
